Yamaha YDX-MORO 07

Yamaha YDX-MORO 07
  • Color: Raven/Silver
  • Color: Dual Blue
$6,399.99 - $6,799.99
Please select options

Details

Fortune tellers will be looking for new jobs when this bike hits your trails. With geometry enchanted to help you predict the future and power delivery characteristics that will raise your spirits, the YDX-MORO 07 will inspire you to go for one more loop.

Geometry Chart:
SMALLMEDIUMLARGE
A 572 619 666
B 388 432 478
C 611 619 624
D 746 755 763
E 111 120 125
F 66.3° 66.3° 66.3°
G 70.3° 70.3° 70.3°
- 780 780 780
- 170 170 170
- 412 459 459
- 40 40 40
- 19 19 19
- 469 469 469
- 1157 1205 1253
- 390 400 410
Sizes:
SizeRider Height
Small 5'2"-5'6"
Medium 5'6"-5'11"
Large 5'9"-6'7"

Specs

Motor YAMAHA PW-X3
Pedals Included
Battery Yamaha 500Wh with Charge-life indicator and Self-diagnosis display Anti-Vibration Mounting Plate Weight: 6.61 lbs 500Wh 36V 4-hour charge time
Controller/Display YAMAHA INTERFACE X
Fork ROCKSHOX LYRIK SELECT 160mm TRAVEL
Rims Aluminum
Stem Alloy 4-both faceplate 35.0 diameter 40mm length
Chain KMC eTURBO EPT 122 links
Frame YAMAHA Dual Twin Frame Tapered Headtube Internal cable/housing routing 2-bolt drive unit mount 12x148 rear axle spacing Integrated YAMAHA speed sensor harness
Tires MAXXIS 27.5X2.6 (F) MINION DHF (R) REKON
Brakes MAGURA MT5 4-PISTON F/R 203MM CENTERLOCK ROTOR (F/R)
Saddle Velo/Yamaha
Spokes 14g alloy
Wheels Aluminum
Headset Integrated 1 1/8"
Crankset PRAXIS E-CRANK ARM 165mm LENGTH
Seatpost TRANZX 30.9 dia. TRAVEL (S) 125mm (M) 150mm (L) 170mm
Shifters Shimano XT SL-M8100-R
Chainrings Samox 36T
Handlebars Alloy 35.0 diameter 780mm width 30mm rise
Rear Shock ROCKSHOX SUPER DELUXE SELECT +
Tape/Grips VELO Single Ring Locking
Brake Levers MAGURA MT5
Rear Derailleur Shimano XT RD-M8100-SGS
Accessories & Extras ISCG05 chainguuide, Safety bell, 3-Year Warranty on Frame, Motor, Battery*
Cassette/Freewheel Shimano XT CS-M8100-12 (10-51T)

* Subject to change without notice.

Part Numbers

Option MPN Store SKU
Raven/Silver / Small YMOR7SRVNSIL YDX16425303S
Raven/Silver / Medium YMOR7MRVNSIL YDX16713795M
Raven/Silver / Large YMOR7LRVNSIL YDX167486L
Dual Blue / Small YMOR7SDBLUE YDX14921346S
Dual Blue / Medium YMOR7MDBLUE YDX14741451M
Dual Blue / Large YMOR7LDBLUE YDX1489009L
